ADDITION (+)

Overview

The ADDITION operator adds two inputs after aligning them to their common dimensions. In other words, addition uses the intersection of the shared dimensions.

The result keeps the coarser level in each shared dimension. Dimensions that exist on only one side are aggregated away.

Use this operator to combine values from two or more nodes.

Syntax

'Node1' + 'Node2'

Example usage: 'Revenue BU1' + 'Revenue BU2'

Parameters

Parameter	Description	Type	Required
Node1	First input node, specified in single quotes (e.g. `'Revenue BU1'`)	Node reference	Yes
Node2	Second input node, specified in single quotes (e.g. `'Revenue BU2'`)	Node reference	Yes

Output Shape

Aspect	Behavior
Dimensionality	Both inputs are aggregated to their common dimensions (the intersection of the shared dimensions). Per shared dimension, the coarser level is used. Dimensions that exist on only one side are aggregated away.
Level values	Non-matching level values are preserved in the result.
Row count	Equal or reduced, depending on how much aggregation is required before adding.

Watch Out

Addition uses the common dimensions (intersection), not the combined dimension set. This is different from multiplication and division.
When adding a constant such as 'Revenue' + 100, the node is aggregated first and the constant is then added to the total.
To add a value to each entry before aggregation, use ADDEACH instead.
Both sides must have the same unit, unless one side is a scalar value.

Examples

Adding nodes with different dimensionality

This example shows how addition aggregates Node B to the common dimensions before adding it to Node A.

Input node: A

Year	Value
2025	5
2026	10

Input node: B

Year	Product	Value
2025	A	2
2026	A	3
2026	B	4

Formula: 'A'+'B'

Year	→ ADDITION Result
2025	5+2 = 7
2026	10+3+4 = 17

Adding nodes with different level values

When level values do not overlap, addition preserves both values in the result.

Input node: A

Year	Value
2025	5

Input node: B

Year	Value
2026	10

Formula: 'A' + 'B'

Year	→ ADDITION Result
2025	5
2026	10

Adding a constant to a node

When one operand is a constant, the node is aggregated first and the constant is then added to the total.

Input node: Sales

Year	Product	Value
2025	A	30
2025	B	20

Formula: 'Sales' + 100

Year	-> ADDITION Result
2025	30 + 20 + 100 = 150

Related Functions

Function	When to use instead
UNION	When both nodes have the same levels and you want to enforce that constraint (stricter version of ADDITION).
ADDEACH	When you need to add a value to each individual entry before aggregation, rather than combining two nodes.
SUBTRACTION (-)	When you need to subtract nodes instead of adding them. Uses the same roll-up logic.
