OpenID Connect

To configure the Valsight application to use the OpenID Connect SSO, edit conf/config.yml and restart the server after making changes.

To enable OpenID Connect login configure the following value:

Configuration Key (loginMethodConfigurations → openIdConnect →)	Description	Example Value	Default Value
enabled	Whether OpenID Connect authentication should be used or not	true	false

To configure an OpenID Connect client enter the following configuration keys:

CODE

spring:
    security:
        oauth2:
            client:
                registration:
                    openIdConnect:
                        .....

Then configure the OpenID Connection client values as follows:

Configuration Key (….registration.openIdConnect →)	Description	Example Value	Default Value
client-id	OAuth 2.0 Client Identifier valid at the Authorization Server	jmxDcfi1gEffVMktJ	n/a
client-authentication-method	The type of client authentication to perform with the Authorization Server. the currently supported forms of authentication are: client_secret_basic private_key_jwt Note: if using ‘client_secret_basic’ then a ‘client-secret’ must be provided, while when using ‘private_key_jwt' then a 'privateRSAKeyPath’ must be provided. For further information about ‘private_key_jwt’ client authentication see https://docs.valsight.com/on-premise/latest/oauth-2-0-with-private-key-jwt-client-authenticait	client_secret_basic	client_secret_basic
client-secret	Client Secret token, provided by the Authorization Server Note: Since 6.3.0 this value is no longer mandatory if not using the 'client_secret_basic' as the client authentication mode	aZWAuRZUSxT-Sh8-xDLdHI	n/a
scope	List of comma separated scopes if we want fetch additional claims.	openid, email,profile	n/a
provider	The name of an OpenID connect provider to use (see below). If there is no provider with the registration id “openIdConnect” a value must be specified.	openIdConnect	n/a
valsightOpenIdConnectProperties → userProfileMapping →username	The claim used to uniquely identify an user. It must always be present in the provider's response and unique per user. Note: claim names are case sensitve, ensure that the configured string matches the IdP claim name exactly.	preferred_username	sub
valsightOpenIdConnectProperties → userProfileMapping → email	The claim that contains the user's e-mail address. Note: claim names are case sensitve, ensure that the configured string matches the IdP claim name exactly. _Optional*	email	n/a
valsightOpenIdConnectProperties → userProfileMapping → fullName	The claim that contains the user's full name. Note: claim names are case sensitve, ensure that the configured string matches the IdP claim name exactly. _Optional*	name	n/a
valsightOpenIdConnectProperties → loginSuccessfulUrl	The absolute URL (starting with http(s)) of the application's main page. The user will be redirected there after a successful login.	https://valsight.company.com/	n/a
valsightOpenIdConnectProperties → forceGroupsOverage	Forces the application to always use the 'https://graph.microsoft.com/v1.0' API to fetch the user's groups. It has no effect if 'groupsClaim' is not enabled. _Optional*	true	false
valsightOpenIdConnectProperties → acr_values	Allows to pass additional authentication related information to the user service. _Optional*	myvalue1:myvalue2:myvalue3:myvalue4	n/a
valsightOpenIdConnectProperties →mandatoryClaims → claim → claimValue	This is used to customize the requested presence and values of claims beyond the ones requested by the OpenID Connect specification. Each claim configured here must be present in the provider's response and also have the specified value. If claim has multiple values in the response (e. g. a list of groups the users belongs to) then one of the values in the response must be an exact match to the configured value. Note: claim names are case sensitve, ensure that the configured strings for ‘claim’ values matches the IdP claim name exactly. _Optional*	Example Configuration CODE `mandatoryClaims: group: groupName role: roleName`	n/a
valsightOpenIdConnectProperties → groupsClaim	This configuration option enables OpenID Connect to determine which groups users belong to. If this field is not present or if it is empty, the groups must be managed internally in the application. If we set a value of 'groupsClaim' we turn this functionality on. The value of 'groupsClaim' should be a claim name that contains the by OpenID Connect provided groups. The group matching happens as follows: read groups from the OpenID Connect response create groups that are missing in the application add user to all groups from the response remove user from all groups not in the response Important: this functionality never automatically deletes groups in the application Note: claim names are case sensitve, ensure that the configured string matches the IdP claim name exactly. _Optional*	groupsInOpenIDConnectResponse	n/a
valsightOpenIdConnectProperties → requiredGroupNamePrefix	REMOVED This field determines if group names must have a specified prefix to be recognised by the application. If this value is set then any group names within the OpenID Connect response that do not start with value will be treated as if they were not present in the response. Note: If a value for loginMethodConfigurations → commonSSOOptions → mandatoryGroupName has been set then the mandatory group name must have the required prefix value. See https://valsight.atlassian.net/wiki/spaces/RND/pages/4988010533 for further details on this setting. _Optional* _{Available since 5.9.1}* *_{Removed and replaced by ‘loginMethodConfigurations → commonSSOOptions → requiredGroupNamePrefixes’ in version 6.0.0 for details see:}https://valsight.atlassian.net/wiki/spaces/RND/pages/4988010533	AcceptedGroup_	n/a
valsightOpenIdConnectProperties → userInfoEndpointScopes	Allows for the configuration of a list of scopes that are accessible only from the user info endpoint, not from the token. If you never want the user info endpoint to be invoked populate this list with none of the scopes listed in the ‘scope’ configuration key (see above). Setting this key to an empty list means the user info endpoint will always be invoked. _{Available since 6.0.26}*	Example Configuration CODE `userInfoEndpointScopes: - profile - email`	profile, email, address, phone

To configure an OpenID Connect provider enter the following configuration keys:

CODE

spring:
    security:
        oauth2:
            client:
                provider:
                  openIdConnect:
                        .....

Then configure the OpenID Connection provider values as follows:

Configuration Key (….provider.openIdConnect →)	Description	Example Value	Default Value
issuer-uri	Identifier for the Issuer of the authorization response.	https://my-oidc.com/	n/a
authorization-uri	The Authorization endpoint of the OpenID Connect flow	https://my-oidc.com/authorize	n/a
token-uri	The Token endpoint of the OpenID Connect flow	https://my-oidc.com/oauth/token	n/a
jwk-set-uri	The endpoint that contains certificates to verify the token	https://my-oidc.com/oauth2/certs	n/a

Full example YAML configuration

Below is an example of all the available configuration keys for OpenID connect, with no values supplied except where stated:

CODE

spring:
    security:
        oauth2:
            client:
                registration:
                        openIdConnect:
                             client-id:
                             client-secret:
                             scope:
                             valsightOpenIdConnectProperties:
                                userProfileMapping:
                                  username:
                                  email:
                                  fullName:
                                forceGroupOverage:
                                loginSuccessfulUrl:
                                mandatoryClaims:
                                  #example value
                                  group: groupName
                                acr_values:
                                groupsClaim:
                                requiredGroupNamePrefix:
                                userInfoEndpointScopes:
                provider:
                         openIdConnect:
                             issuer-uri:
                             authorization-uri:
                             token-uri:
                             jwk-set-uri:

Logging

For logging purpose, add in the log level view (Configuration UI), the following package:

org.springframework.security
org.springframework.security.oauth2
com.valsight.authentication.oauth
com.valsight.services.authentication.SSOService
com.valsight.authentication
org.springframework.web.client

Set the log level to DEBUG

Redirect/callback URL

When configuring the IdP the redirect/callback URL for the application is:

<server_url>/<contextPath>/login/oauth2/code/openIdConnect

Reverse Proxy Configuration

If the application is running behind a reverse proxy it will be required to configure the reverse proxy such that the OpenID connect authentication flow can be performed A guide to doing this can be found here: Reverse Proxy
